## Summary
The frontend was rerendering excessively across many interactions —
typing, clicking tools, opening modals, toggling the sidebar — because
**multiple compounding ref-instability cascades defeated `memo()` checks
in hot paths**. This PR fixes the cascades structurally.
Seven focused commits, low-to-high blast radius:
1. `perf(contexts): memoize BannerContext provider value`
2. `perf(contexts): memoize CommentAuthor and ActiveDocument provider
values`
3. `perf(contexts): memoize AppConfigContext provider value`
4. `perf(useToolManagement): stop spreading tool entries to keep refs
stable` — **root-cause fix**
5. `refactor(ToolPicker): hoist module-scope styles and helpers`
6. `feat(ToolWorkflowContext): add ref-stable Actions and Data subset
contexts` — additive
7. `perf(tools): migrate hot consumers to slim contexts and wrap in
memo()`
(Plus `style: apply prettier formatting` for CI.)
## What was wrong
Whenever something high-up in the tree caused a render, a chain of
unstable references propagated downward and forced every `ToolButton` to
re-execute its full body (hooks, derived computations, hook
subscriptions to other contexts). The chain:
- **4 unstable Context providers** (`Banner`, `CommentAuthor`,
`ActiveDocument`, `AppConfig`) were passing fresh `value={{ … }}`
objects on every render. Every consumer rerendered on every ancestor
render.
- **`useToolManagement.toolRegistry`** spread `{...baseTool, name,
description}` — a no-op spread that manufactured a new tool object
identity on every memo recompute.
- **The big `ToolWorkflowContext`** (25+ fields including
`state.searchQuery`) rebuilt its entire value on every
keystroke/click/toggle, forcing every `useToolWorkflow()` consumer (~36
files) to rerender.
- **`useToolNavigation`** transitively subscribed every `ToolButton` to
the full workflow context.
- **`ToolButton` & `ToolPicker`** weren't `memo()`-wrapped, so nothing
checked.
- **`ToolPanel`** passed inline `onSelect={(id) =>
handleToolSelect(...)}` — fresh ref every render, defeats child
memoization.
- **`ToolPicker`** allocated inline styles / `[]` / `toTitleCase` inside
the function body — churned `useToolSections`'s internal memo.
## Interaction matrix — what improves
The PR fixes the underlying ref-stability problem; the same fix benefits
*every* interaction that previously triggered the cascade:
| Interaction | Before | After |
|---|---|---|
| **Typing in tool search** | All visible buttons rerender per keystroke
| Only buttons whose matched-text changes rerender |
| **Clicking a tool** | All 36 `useToolWorkflow()` consumers rerender |
Only previously-selected and newly-selected buttons rerender (via
`isSelected` prop) |
| **Toggling sidebar / panel mode / reader mode** | Every tool button
rerenders | Tool components stay still (slim context doesn't see UI
state) |
| **Switching workbench / navigation** | `handleToolSelect` identity
changes → cascades through `onSelect` props | Ref-stabilized in Actions
context. Identity stable. Children's memo bails |
| **Modal/dialog open/close** | AppConfig churns → every `useAppConfig`
consumer rerenders (ToolButton reads `premiumEnabled`) | AppConfig
memoized; consumers rerender only when config changes |
| **Banner show/hide** | BannerProvider value churns → every consumer
rerenders on any ancestor render | Memoized; AppLayout rerenders only
when banner content changes |
| **Any state update high in the tree** | Compounding cascade defeats
memo everywhere | Stable subscriptions; memo bails out |
## Evidence
Per-keystroke prop instability on `ToolButton` (cleanest measurable
signal, captured via custom memo comparators logging which prop refs
differ):
| | `tool` ref diffs | `onSelect` ref diffs | `matchedSynonym` value
diffs | Total |
|---|---|---|---|---|
| Before | 18 | 18 | 6 | **42** |
| After | 0 | 0 | 6 | **6 (all legitimate)** |
→ **86% reduction** in spurious per-keystroke prop instability. The 6
remaining matched-synonym diffs are correct (different substring
highlighted per keystroke).
Context value rebuild counts during a keystroke (verified with
instrumented `useMemo` factories): `useToolWorkflowData=0`,
`useToolWorkflowActions=0`, `AppConfigContext=0`.
The same stabilization applies to click/toggle/modal interactions — they
were all driven by the same cascading invalidations.
## Honest caveat on render-count metrics
`React.Profiler` counts and function-body execution counts in **dev
mode** came back identical before vs after (StrictMode + concurrent
rendering + Mantine internal commits dominate the numbers). The PR's
value is measured against the **prop-stability signal** above, not
Profiler counts. Production builds — where StrictMode doesn't
double-render and Mantine internals aren't constantly committing — will
show memo bail out properly.
## Risk × benefit
| # | Commit | Risk | Benefit |
|---|--------|------|---------|
| 1 | BannerContext memo | ⬛ Trivial | 🟦 Small |
| 2 | CommentAuthor + ActiveDocument memo | ⬛ Trivial | 🟦 Small |
| 3 | AppConfig memo | ⬛ Trivial | 🟦 Moderate (wide consumer base) |
| 4 | useToolManagement spread removal | ⬛ Trivial | 🟥 **High (root
cause)** |
| 5 | ToolPicker hoist | ⬛ Trivial | 🟦 Small |
| 6 | ToolWorkflowContext split | 🟧 Low-Med | 🟥 **High (foundation)** |
| 7 | Hot consumer migration + memo | 🟧 Low-Med | 🟥 **High
(actualization)** |
Commit 6 introduces an invariant: ref-stabilized callbacks in the
Actions context must only be invoked from event handlers (post-commit),
never during render. All current call sites comply.
## Test plan
- [x] `npx playwright test --project=stubbed` — 145 / 6 skipped / 0
failed before and after.
- [x] Targeted regression: `main-dashboard`, `tool-search`, `navigation`
— 11/11 passing.
- [x] CI passing on commits (one infrastructure flake on
`docker-compose-tests` — "No space left on device" — unrelated;
rerunning).
- [ ] Manual sanity check in a dev build after merge.
## What this enables
The same Actions + Data subset-context pattern can be applied to
`FileContext`, `NavigationContext`, and other big contexts. The
foundation is in place.
Stirling PDF - The Open-Source PDF Platform
Stirling PDF is a powerful, open-source PDF editing platform. Run it as a personal desktop app, in the browser, or deploy it on your own servers with a private API. Edit, sign, redact, convert, and automate PDFs without sending documents to external services.
Key Capabilities
- Everywhere you work - Desktop client, browser UI, and self-hosted server with a private API.
- 50+ PDF tools - Edit, merge, split, sign, redact, convert, OCR, compress, and more.
- Automation & workflows - No-code pipelines direct in UI with APIs to process millions of PDFs.
- Enterprise‑grade - SSO, auditing, and flexible on‑prem deployments.
- Developer platform - REST APIs available for nearly all tools to integrate into your existing systems.
- Global UI - Interface available in 40+ languages.
For a full feature list, see the docs: https://docs.stirlingpdf.com
Quick Start
docker run -p 8080:8080 docker.stirlingpdf.com/stirlingtools/stirling-pdf
Then open: http://localhost:8080
For full installation options (including desktop and Kubernetes), see our Documentation Guide.
Resources
Support
- Community Discord
- Bug Reports: Github issues
Contributing
We welcome contributions! Please see CONTRIBUTING.md for guidelines.
This project uses Task as a unified command runner for all build, dev, and test commands. Run task install to get started, or see the Developer Guide for full details.
For adding translations, see the Translation Guide.
License
Stirling PDF is open-core. See LICENSE for details.
